Adopting helical gear noise reduction technology, smoother noise;
Adopting high-strength aluminium alloy material, light weight and easy installation;
Axial clearance automatic compensation mechanism, radial hydraulic balance, to maintain high volumetric efficiency of the oil pump;
Adopting self-lubricating bearings to improve the carrying capacity of the pump;
Inlet and outlet coupling forms are threaded and flanged for choice;
Input shaft coupling form can choose flat key, rectangular spline;
Higher volumetric efficiency at 400rpm;

Nominal Displacement :4-20mL/r
Rated pressure :28MPa
Maximum pressure :31.5MPa
Rated speed :2000r/min
Speed range:800-3000r/min
Noise value:<65dB(A)
